Data Editing
118 QuickScan
TM
QD2100
Character Conversion
Character conversion is an eight byte configuration item. The eight bytes are 4 character
pairs represented in hexadecimal ASCII values. The first character in the pair is the char-
acter that will be converted. The second character in the pair is the character to convert
to. If the character to convert in a pair is FF, then no conversion is done.
For example, if you have the character conversion configura
tion item set to the following:
41423132FFFFFFFF
The first pair is 4142 or AB (41 hex is an ASCII capital A, 42 hex is an ASCII capital B)
and the second pair is 3132 or 12 (31 hex is an ASCII 1, 32 is an ASCII 2). The other
two pa
irs are FFFF and FFFF.
With the label, AB12BA21, it would look as follows after the character
conversion: BB22BB22.
The A characters were converted to B characters and the 1 characters were converted to
2 characters. Nothing is done with the last two character pairs, since they are all FF.
To set Character Conversion:
1. Scan the ENTER/EXIT bar code.
2. Scan the “Configure Character Conversion” bar code.
3. Determine the desired string. Sixteen positions must be determined as in the above exam-
ple. Next, turn to the ASCII Chart on the inside back cover of this manual and find the
equiv
alent hex digits needed to fulfill the string.
4. Turn to Appendix E, Keypad and scan the bar codes representing the hex characters
determined in the previous step.
5. Scan the ENTER/EXIT bar code to exit Programming Mode.
NOTE
If less than the expected string of 16
characters are selected,
scan the ENTER/EXIT bar code twice to accept the selections
and exit Programming Mode.
