Datalogic 2 of 5

Product Reference Guide

215

Datalogic 2 of 5 — cont.

Datalogic 2 of 5 Check Character Calculation

This option enables/disables calculation and verification of an optional Datalogic 2 of 5

check character.

ENTER/EXIT PROGRAMMING MODE

DEFAULT

Datalogic 2 of 5 Check Character Calculation = Disable

Datalogic 2 of 5 Check Character Calculation = Enable
