Generating Label Formats
Class Series Programmer’s Manual 135
eee: Bar Code Height (Font Size/Selection)
This field has interpretations dependent upon the value of the font b field, as shown below.
b Font Field Value eee Field Range eee Field Interpretation
0-8
000 Not used –Internal bitmapped font
9
000-999, A04-A72, S00-S9z,
U00-U9z, u00-u9z
Font height; Font selection
A-T
000-999 Bar code height (with human readable)
a-z
000-999 Bar code height
Wxx
000-999 Bar code height (with human readable)
X,Y
000 Not used
Table 8-5: Bar Code Height Field Interpretations
ffff: Row Position
The lower left corner of a label is considered the “home position” (see Figure 8-1). The row
position field is a vertical coordinate that determines how far above the home position the data is to
be printed. Field data is interpreted in hundredths of an inch or tenths of millimeters.
gggg: Column Position
This field is a horizontal coordinate that determines how far to the right of “home position” the
data will be printed. Appendix G lists the maximum values of the gggg field.
hhhh: Optional Scalable Font Height
The height of a scalable font can be specified in two ways: points or dots. To specify the height in
points the first character of the field is a ‘P’ followed by the number of points, 004 to 999. To
specify the size in dots, all four characters must be numeric. This field must be specified for
scalable fonts. (See note below Optional Scalable Font Width.)
iiii: Optional Scalable Font Width
The width of a scalable font can be specified in two ways, points or dots. To specify the width in
points, the first character of the field is a ‘P’ followed by the number of points, 004 to 999 points.
To specify the size in dots, all four characters must be numeric. This field must be specified for
scalable fonts. See note below.
Note: To ensure that the data stream is portable to different Datamax printers, specify the font size in
points. If the font is specified in dots, it will output differently on printers with different DPI/MMPI
resolutions. There are 72.307 points per 1 inch (2.847 mm).
