Appendix F – Barcode Summary Data
180 Class Series Programmer’s Manual
203 DPI Resolutions 300 DPI Resolutions 400 DPI Resolutions 600 DPI Resolutions
Font
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
U/u
1.00 N/A 1.00 N/A 1.00 N/A 1.00 N/A
v
.5 1 .5 1 .5 2 .5 3
z
N/A N/A N/A N/A N/A N/A N/A N/A
Z/z
N/A N/A N/A N/A N/A N/A N/A N/A
W1C/W1c
N/A N/A N/A N/A N/A N/A N/A N/A
W1D/W1d
N/A N/A N/A N/A N/A N/A N/A N/A
W1F/W1f
N/A N/A N/A N/A N/A N/A N/A N/A
W1I
.40 2 .40 4 .40 4 .40 6
W1J
.40 2 .40 4 .40 4 .40 6
W1k
N/A 2 N/A 3 N/A 4 N/A 6
W1p
N/A N/A N/A N/A N/A N/A N/A N/A
W1G/W1g
.5 5:2 .5 7:3 .5 9:4 .5 14:6
W1R
1.40 2 1.40 4 1.40 4 1.40 6
W1T
.40 6:2 .40 9:4 .40 12:4 .40 18:6
W1Z/W1z
N/A N/A N/A N/A N/A N/A N/A N/A
Table F-2: Bar Code Default Data
 Note: Some bar codes will be sensitive to Label Command ‘D’ (set dot width and height size); see Label Formatting Commands for details.
