Appendix G – Barcode Details
212 Class Series Programmer’s Manual
Field Valid Inputs Meaning
a
1,2,3, and 4 Rotation
W1
W1 Fixed value, extended bar code set
k
k Selects GS1 DataBar bar code
c
1 to 9, A to Z, and a to z Wide bar ratio, default = 2
d
1 to 9, A to Z, and a to z Narrow bar ratio, default = 2
eee
000 No effect
ffff
0000 to 9999 Label position, row
gggg
0000 to 9999 Label position, column
h
R, T, S, D, L GS1 DataBar Type: R = GS1 DataBar,
T = GS1 DataBar Truncated,
S = GS1 DataBar Stacked,
D = GS1 DataBar Omni-Directional,
L = GS1 DataBar Limited
i
1-9 Pixel Multiplier
j
0 to (i-1) X pixels to undercut
m
0 to (i-1) Y pixels to undercut
n…n
0 to 9 Numeric linear data, length 13
[1]
|
| (optional) Vertical bar separates primary linear data from secondary
2-D data
p…p
2-D data (optional) Additional 2-D data
[2]
[1]
The application identifier is not encoded in the symbol nor is the last check digit; the user should enter in a
13-digit value. The decoding system will display the application identifier and calculate the check digit.
[2]
The separator row height for two-dimensional composite is fixed at one times the pixel multiplier.
Table G-5: GS1 DataBar, Truncated, Stacked, Stacked Omni-Directional, & Limited Record
Structures
Examples:
The following example prints an GS1 DataBar bar code.
<STX>L
D11
1W1k0000001500150R1002001234567890
121100000000100Barcode W1k<CR>
E
Barcode W1k
The following example prints an GS1 DataBar bar code with 2-D data.
<STX>L
D11
1W1k0000001500150R1002001234567890|123456-99/99/99
121100000000100Barcode W1k<CR>
E
Barcode W1k
