Appendix S – Line Mode

Class Series Programmer’s Manual 269

The sample data will print the following two labels (layout and typeface are approximations):

Label 1:

TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA

FIXED FIELD #1

TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB

FIXED FIELD #2

TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC

Label 2:

TEST DATA DDDDDDDDDDDDDDDDDDDDDDDDD

FIXED FIELD #1

TEST DATA EEEEEEEEEEEEEEEEEEEEEEEEE

FIXED FIELD #2

TEST DATA FFFFFFFFFFFFFFFFFFFFFFFFF

Sample DMXFRMxx Template:

If a template in the form of DMXFRMxx is used, the data must be preceded by the value of xx. Below is a

sample template for DMXFRMxx:

<STX>L

D11

15110000160001099999999999999999999999999999999999

151100001200010FIXED FIELD NUMBER ONE

15110000080001099999999999999999999999999999999999

151100000400010FIXED FIELD NUMBER TWO

15110000000001099999999999999999999999999999999999

Q0001

sCDMXFRMA1
