138 A-Class
PRINT SIGNAL INFO: A hardcopy of the current GPI/O settings and signal states can
be output (see Section 4.2.6, TEST GPIO / PRINT SIGNAL INFO) in the following format:
GPIO SIGNAL INFO
WED 11:04AM 4JUL2005
CARD ID#3
OUTPUT SIGNALS
END OF PRINT
PIN# 11 GPIO A
LOW PULSE
CURRENT LEVEL 1
RIBBON LOW
PIN# 9 GPIO A
ACTIVE LOW
CURRENT LEVEL 0
SERVICE REQUIRED
PIN# 10 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
MEDIA OUT
PIN# 12 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
RIBBON OUT
PIN# 13 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
DATA READY
PIN# 14 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
OPTION FAULT
PIN# 15 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
INPUT SIGNALS
START OF PRINT
PIN# 3 GPIO A
ACTIVE HIGH
CURRENT LEVEL 1
FEED
PIN# 4 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
TOGGLE PAUSE
PIN# 5 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
REPRINT
PIN# 6 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
o1
PIN# 15 GPIO B
CURRENT LEVEL 1
o2
PIN# 10 GPIO B
CURRENT LEVEL 0
o3
PIN# 5 GPIO B
CURRENT LEVEL 1
o4
PIN# 14 GPIO B
CURRENT LEVEL 1
o5
PIN# 9 GPIO B
CURRENT LEVEL 1
o6
PIN# 4 GPIO B
CURRENT LEVEL 1
i1
PIN# 13 GPIO B
CURRENT LEVEL 1
i2
PIN# 8 GPIO B
CURRENT LEVEL 0
i3
PIN# 3 GPIO B
CURRENT LEVEL 1
i4
PIN# 12 GPIO B
CURRENT LEVEL 1
i5
PIN# 7 GPIO B
CURRENT LEVEL 1
i6
PIN# 2 GPIO B
CURRENT LEVEL 1
