130 M-Class
Windows NT 4.0 Driver and Port Installation
Insert the M-Class CD-ROM into your computer’s drive.
The M-Class CD-ROM should start automatically, if it does not Click
‘Start’ and then select ‘Run’ from the window’s menu. Then type
d:\datamax.exe
(where “d:” is the location of the CD-ROM)
1
At the main screen click
on your printer model.
2
Now click “Install
Windows Driver”.
3
Make sure that ‘My
Computer’ is selected
and then click ‘Next’.
4
Click ‘Add Port’.

Datamax M-Class Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Print Speed	6 IPS (152 mm/s)
Interface	USB, Serial, Ethernet, Parallel
Media Sensor	Reflective and Transmissive
Supported Media Types	Labels, Tags
Media Thickness	0.0025" (0.0635 mm)
