Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 3 - 15
Repair Information Disassembly Instructions
IABP Cable (ECG/IBP)
(only for serial numbers TSXXXXX-J5 and higher)
FIGURE 3-3 IABP Cable (ECG/IBP) (P/N 0012-00-1650-01)
Connector shell
Shield drain wire
BLK
WHT
RED
AOUT1 (ECG) 1
AOUT2 (PRESS) 2
GNDA 3
AIN 4
GND 5
DOUT 6
P2, ECG
P3, PRESS
P1
TIP
SLV
RING
TIP
SLV
RING
BLK
BRN
BLK
BRN
See Note
N.C.
N.C.
N.C.
1
2
3
4
5
6
P1
2
4
1
P2
P3
3
5
5
5
