Datascope Passport 2 - Page 86

Disassembly Instructions Repair Information
3 - 20 0070-10-0441 Passport 2®/Passport 2 LT™ Service Manual
Serial Port to Gas Module Cable
PART NUMBER LENGTH AND DESCRIPTION
0012-00-1276-01 12 inch 9 pin mini D serial to 25 pin D shell
0012-00-1276-02 72 inch 9 pin mini D serial to 25 pin D shell
2X +/-.131.00
L
1
5
6
9
SEE DETAIL A
DETAIL A
P1
P2
7
16 17 18 19 20 22 23
7
16 17 18 19 20 22 23
24-25
1-6
7
8-21
23
22
1
2
3
4
5
6-9
P1
P2
