Passport 2®/Passport 2 LT™ Service Manual 0070-10-0441 3 - 21
Repair Information Disassembly Instructions
Nurse Call Cable (3 pin circular to unterminated)
P/N 0012-00-1277-02
cable
shield
cable
shield
3
2
1
connector
shield
BLK
WHT
RED
E1
E2
E3
E4 E7
E6
E5
E8
circuit board
Blk NC
Red No
White Common
