STEP 3 – Using the DAC’s PCM Inputs
The DAC has 5 standard PCM inputs, which may be used with a wide variety of sources.
Switch on the source equipment. If appropriate, load a disk / tape / file and set the machine in PLAY
mode to ensure it is generating a digital audio data stream.
Choose one or both of the following two sections:
Connecting to a Dual AES Source
• Check that your source equipment is capable of Dual AES operation and is set up correctly. This
will probably a dCS SACD Transport, a dCS Upsampler or a sound server.
Press Menu, ►, ►, Menu, to select the Unit Settings > Dual AES menu page and use the
Menu button to ensure it is set to Auto.
• Connect the AES1 (or AES A) output on your source equipment to the AES1 input on the DAC’s
rear panel and the AES2 (or AES B) output to the AES2 input, using two XLR cables. Ensure the
cables are not swapped.
Figure 3 – Using the Bartók DAC with the Rossini CD/SACD Transport
• Use the Input button to select the AES1 input.
If this icon is not displayed, open the Menu and select Unit Settings > Sync Mode >
Audio Sync.
The DAC will lock to the source and automatically select AES1+2, displaying 24/352.8 for example, if
the source is generating that format.
Analogue outputs
