DCS Bartok - Navigating the Menu System; Menu Structure and Navigation Overview

dCS Bartók DAC User Manual Software Issue 1.0x
February 2019
Bartok DAC Manual v1_0x Page 38 English version
THE MENU
The STEP > button moves along the menu, the STEP < button moves back.
MENU
Press the MENU button to set a menu option or change options.
Information
►
Unit Status
►
Version
►
Contact
►
Update
Audio
Settings
►
Phase
►
Filter
►
DSD Filter
►
Channel
Swap
►
Balance
Changes the
output phase
for both
channels.
Selects an
optional filter if
available
Selects a DSD
filter.
Reverse the
Left and Right
outputs
Allows Balance
adjustment by
rotary control
Unit
Settings
►
Sync Mode
►
Line Level
►
Dual AES
►
USB Class
►
Buffer
►
Upsampling
►
RS232
Mode
Sets the clock
source for the
selected input.
Sets the level
for the Line
Outputs.
Enables Dual
AES operation
Selects USB
Class 1
(24/96) or
Class 2
(24/384)
Buffers the
data to reduce
clicks when
the input rate
changes.
Allows DSD
upsampling.
Select RS232
Text Mode or
Binary Mode.
Displays the
unit status.
Displays the
software
issues.
Displays dCS
contact details.
Loads new
software from
a dCS update
disc.
Config
►
Lock
►
Save
►
Restore
►
Reset
Names
►
Factory
Reset
Locks some
important
settings.
Saves the
current config
to memor y .
Loads the
previously
saved config
from memory .
Resets the
user-selected
input names to
standard.
Restores
standard
factory
settings.
Display
Settings
►
Brightness
►
Display
On/Off
►
Logo
Sets the
display
brightness.
Tur ns the main
display on/off.
Turns the dCS
Logo
illumination
on/off
