UNIT SETTINGS Menu
These settings are usually “set and forget”.
Sync Mode
This page sets the clocking for the digital input that is currently selected. The DAC
remembers the Sync Mode setting separately for each digital input. The options are:
Audio – The DAC extracts the clock from the data stream connected to the selected digital
input and locks to it. Use this setting for sources that do not have a suitable Word Clock
input. This arrangement does NOT give the best jitter performance or the best sound
quality. The USB and Network inputs or cannot be set to Audio Sync.
Master – This is the normal mode for the asynchronous USB and Network inputs where a
Master clock is not available. The DAC uses its own internal clock to control the internal
DAC and regulate delivery of data packets. In this situation, the DAC is acting as the
source device.
When using the AES or SPDIF inputs in Master Mode, the DAC again uses its internal
clock to control the DAC and outputs a clock signal at the Word Clock Output. For correct
Master Mode operation, the source’s word clock input MUST be locked to the DAC’s
Word Clock Output – this ensures that the source is delivering data at the correct rate.
Word Clock 1-2 Auto – This mode is designed for easy operation with a Master Clock in a
computer audio system, where the data rate may keep changing. Connect the Word
Clock In1 input to a Clock output set to 44.1 or 88.2 or 176.4kHz and connect the Word
Clock In2 input to a Clock output set to 48, 96 or 192kHz. When the sample rate changes,
the DAC will automatically select a Word Clock frequency that is synchronous with the
data. The selected word clock input appears on the main display.
Word Clock 1 – The DAC locks to an external clock connected to Word Clock In1.
Word Clock 2 – The DAC locks to an external clock connected to Word Clock In2.
If the DAC cannot find a word clock that is synchronous with the data on the selected AES
or SPDIF input, it will default to Audio sync and display the “Bad Clock” icon.
Line Level
This page sets the full scale line output level to 6V, 2V, 0.6V or 0.2V rms to allow you to
match the DAC’s line output level to your amplifiers, speakers and room.
When you set up your system, choose the Line Level setting that gives a comfortable
listening level with the Volume set between –10dB and –30dB. The difference between
two adjacent settings is about 10dB.
The lower settings are also intended to prevent accidents when driving the amplifiers
directly and AirPlay is in use, as the Volume set by the sending device can be very high.
