6 Connecting diagrams and configuration
6.1 Factory settings for circuits
In the factory, the different circuits are configured as indicated in the table.
You can modify this configuration and adapt it to the needs of your
installation. Three installation types are described here to provide a guide.
Tab.4
Circuit Circuit type Specifications
CIRCA Direct heating circuit Gradient: 1.5
Maximum temperature: 90 °C
CIRCB
CIRCC (optional)
AUX (optional)
Circuit with mixing valve Gradient: 0.7
Maximum temperature: 50 °C
DHW Domestic hot water circuit Set point temperature: 55 °C
6.2
Addition of 2 heating circuits + 1 DHW circuit + 1 swimming pool circuit controlled by VM
Diematic Evolution
Tab.5 Packages used in this configuration
AD199 Flow sensor after valve
AD249 Three-way valve PCB and sensor
AD212 (x3) Domestic hot water sensor and TAS
AD309 S-Bus 12 m cable with terminals
AD311 SmartTC° programmable and connected room thermostat
AD250 Sensor for buffer tank or cascade flow
