8. Configure the parameters for the following components:
Tab.8
Component Access Parameter Code Adjustment required
Cascade Analogue input > Adv.
Parameters
Sets the general configuration of
the sensor input 2
EP037 System (cascade)
Recirculating pump AUX Functionality of the zone CP024 Time Program
Stratified tank Analogue input > Adv.
Parameters
Sets the general configuration of
the sensor input 1
EP036 DHW tank top
DHW Functionality of the zone CP022 DHW Layered
Swimming pool CIRCC > Parameters,
counters, signals >
Parameters
Functionality of the zone CP023 Swimming pool
6.3
Cascade of 3 generators, 3 heating circuits and 1 DHW circuit controlled by VM Diematic
Evolution
Tab.9 Packages used
AD199 (x2) Flow sensor after valve
AD309 S-Bus cable with terminals, 12 m
AD249 Three-way valve PCB and sensor
AD250 Sensor for buffer tank or cascade flow
6 Connecting diagrams and configuration
7703592 - v02 - 14062018 19
