8. Configure the parameters for the following components:
Tab.12
Component Access Parameter Code Adjustment required
Cascade Analogue input > Adv.
Parameters
Sets the general configuration of
the sensor input 2
EP037 System (cascade)
Recirculating pump AUX Functionality of the zone CP024 Time Program
Stratified tank Analogue input > Adv.
Parameters
Sets the general configuration of
the sensor input 1
EP036 DHW tank top
DHW Functionality of the zone CP022 DHW Layered
6.4
Cascade of 2 generators + addition of 3 heating circuits + 1 DHW circuit controlled by VM
Diematic Evolution
Tab.13 Packages used
AD134 Mod-Bus 12 m connection cable
AD199 (x2) Flow sensor after valve
AD212 (x2) Domestic hot water tank sensor circuit
AD249 Three-way valve plate
AD311 SmartTC° programmable and connected room thermostat
6 Connecting diagrams and configuration
22 7703592 - v02 - 14062018
