7 GETTING STARTED
7.1 FUNCTIONS
7.1.1 DVR
FRONT
Power
LED
(white the DVR is on)
IR Remote Receiver
(remote control not included)
Hard Drive LED
(red data is being imported/exported)
USB Port
Network LED
(white DVR is connected to a network)
BACK
Video Output (Camera Connections) Audio IN/OUT
USB Port Network Port
HDMI Port Power Adapter
VGA (Monitor) Port Power Switch
7.1.2 Camera
Video Output BNC Connector
Power Input Locking Screw

The Video Output button is an optional feature used to change the video output of the
camera. You can see the results on the Live View screen.
