01/10/2021 ASSEMBLY INSTRUCTIONS MLD Control EC-6 with CCB III Page 31
10.2 Fault report
DEGER D60H
DEGER D80
DEGER D100
DEGER 5000HD
DEGER 6000NT
DEGER 9000NT
DEGER 3000NT
DEGER 3000HD
DEGER 5000NT
Delivery date
DEGER system serial no.
204-
EC-6 serial no.
EMO serial no.
Single system
Energy plant with ……
systems
Wind monitor
CCB ADVANCED
(aluminum, heated)
Ground-mounted Installed on building
Measured values according to
troubleshooting diagram
Yes
No
East-west axis moves to brightest spot (possibly cover up a solar cell).
East-west drive can move in both directions when controlled by the joystick (CCB).
Elevation axis moves to brightest spot (possibly cover up a solar cell).
Elevation drive can move in both directions when controlled by the joystick (CCB).
Control using wind monitor: Moves into horizontal position
Measured values on energy converter
Voltage input
Terminal L - N
V
LED MOTOR POWER OK
Green LED
LED off
LED SENSOR POWER OK
Green LED
LED off
LED EL MOTOR
Terminal 1-2
Green LED
Red LED
LED AZ MOTOR
Terminal 3-4
Green LED
Red LED
LED EL SENS OUT
Terminal 11-12
Green LED
Red LED
LED AZ SENS OUT
Terminal 13-14
Green LED
Red LED
Signal at SAVE POS?
Terminal 20-21
+ or -
V
Signal at external EL?
Terminal 16-17
+ or -
V
Signal at external AZ?
Terminal 18-19
+ or -
V
Power consumption for elevation motor
+ or -
A
Power consumption for azimuth motor (east-west)
A
Jumper settings
J1 J2 J3 J4 J5 J6 J7
Contact
Installer Operator
Company/name
Address
Postal code, city
Contact partner > phone number, e-mail address
Delivery address
For return parts:
DEGERenergie GmbH & Co. KG
Service-
Industriestr. 70
D-72160 Horb a.N.
Germany
Problem description
Spare part needed:
