01/10/2021 ASSEMBLY INSTRUCTIONS MLD Control EC-6 with CCB III Page 22
5 Snow Sensor
5.1 Function
The snow sensor detects
accumulations of snow and ice
on the DEGER system.
When a certain amount of snow
or ice accumulates on the
sensor, a signal is sent to the
CCB, which moves the solar
modules into the greatest
possible
inclined position to facilitate the snow to slide off.
ATTENTION!
Do not change the default switching threshold. Changing the default setting will void any warranty
claims.
5.2 Assembly and positioning
The snow sensor has to be mounted to the lower module
edge of the module surface positioned between the last
vertical rows. It is suitable for module heights up to 65 mm.
1. The 20 cm aluminum profile has to be
mounted to the bottom side of the
module surface using two bolts M6, two
clamp plates and two sliding nuts M6.
Torque: 8 Nm
