Figure 16 Opening the console
21
CL4699
Unlocking and removing the front bezel
About this task
NOTICE You must remove the enclosure’s front bezel to gain access to the disks. The bezel is
required for EMI compliance when the enclosure is powered up. Remove it only to replace or
add a disk.
Procedure
1.
Insert the key that shipped with your enclosure into the bezel lock, and turn it to release the
lock.
2. Press the two latch buttons on the bezel surface to release the bezel from the cabinet.
Figure 17 Releasing the front bezel
CL5667
3. Pull the bezel off and put it on a clean, static-free surface.
Removing and replacing FRUs
Dell EMC ES40 Expansion Shelf Guide Field Replacement Unit Guide 31
