Figure 54
Removing the screws that secure the enclosure to the front of the cabinet
Rear
Front
Screw (2)
Screw (2)
CL4728
2.
With help from another person, slide the enclosure out of the cabinet and place it on a
static-free work surface (
Figure 55
on page 60).
Figure 55
Sliding the enclosure out of the cabinet
CL4718
Removing and replacing FRUs
60
Dell EMC ES40 Expansion Shelf Guide Field Replacement Unit Guide
