Removing the Secondary Hard-Drive (optional) | 21
7 Remove the screws that secure the secondary hard-drive to the secondary
hard-drive bracket.
8 Slide and lift the secondary hard-drive off the secondary hard-drive bracket.
9 Disconnect the interposer from the secondary hard-drive connector.
1 interposer 2 secondary hard-drive connector
3 screws (4) 4 secondary hard-drive bracket
5secondary hard-drive
