Removing the Palm Rest | 33
Procedure
1
Lift the connector latch and pull the pull-tab to disconnect the status-light board cable
from the system-board connector and slide the cable into the slot on the computer
base.
2 Remove the screws that secure the palm-rest assembly to the computer base.
1 connector latch 2 status-light board cable
3screws (9)
