48 | Removing the Keyboard
4 Remove the screws that secure the keyboard bracket to the palm-rest assembly.
5 Lift the keyboard bracket at an angle and release it from the tabs on the palm-rest
assembly.
6 Slide the keyboard cable and keyboard-backlight cable through the keyboard
bracket.
7 Lift the keyboard bracket off the keyboard.
1 screws (8) 2 keyboard bracket
3tabs (4)
book.book Page 48 Monday, June 24, 2013 10:53 AM
