Removing the Keyboard | 49
8 Remove the screws that secure the keyboard to the palm-rest assembly.
9 Lift the keyboard and release it from the tabs on the palm-rest assembly.
1tabs (2) 2keyboard
3 palm-rest assembly 4 screws (2)
4
2
1
3
