Dell Alienware 18 - Page 59

Removing the Display Assembly | 59
11 Remove the screws, on the display hinges, that secure the display assembly to the
computer base.
12 Move the display to a perpendicular position to the computer base, and then lift the
display assembly off the computer.
1 display assembly 2 screws (3)
1
2
Book.book Page 59 Friday, June 28, 2013 11:10 AM
