3. To install a 2230 solid-state drive in SSD slot two, see installing the 2230 solid-state drive in SSD slot two.
4. To install a 2280 solid-state drive in SSD slot two, see installing the 2280 solid-state drive in SSD slot two.
Speakers
Removing the speakers
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the 2280 solid-state drive in SSD slot 2.
NOTE: This step is required if the device is shipped with a 2280 solid-state drive in SSD slot 2.
About this task
The following image indicates the location of the speakers and provides a visual representation of the removal procedure.
34
