Steps

1. Slide the rear I/O-cover onto the palm-rest and keyboard assembly until it snaps into place.

2. Replace the two screws (M2x4) that secure the rear I/O-cover to the palm-rest and keyboard assembly.

3. Connect the Tron light cable to the system board.

4. Replace the two screws (M2.5x5) that secure the rear I/O-cover to the palm-rest and keyboard assembly.

Next steps

1. Install the

base cover.

2. Follow the procedure in After working inside your computer.

Touchpad

Removing the touchpad

Prerequisites

1. Follow the procedure in Before working inside your computer.

2. Remove the base cover.

3. Remove the

battery.
