Removing and installing components
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Recommended tools
The procedures in this document may require the following tools:
Phillips screwdriver #0
Plastic scribe
Screw list
NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then
place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is restored when
the component is replaced.
NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surfaces when replacing a
component.
NOTE: Screw color may vary with the configuration ordered.
Table 1. Screw list
Component Screw type Quantity Screw image
Base cover M2.5x1.7 (captive screw) 4
Base cover M2.5x8.5 (captive screw) 2
Base cover M2.5x5 2
Solid-state drive in SSD Slot one M2x4 2
Solid-state drive in SSD Slot two M2x4 2
I/O board M2x4 1
I/O board M2x2 1
Wireless-card bracket M2x4 1
Display hinges M2.5x5 6
Battery M2x4 4
9
