Dell Alienware m15 R6 - Installing the Heat-Sink Assembly

Steps
1. Disconnect the left and right fan cables from the system board.
2. Turn the system-board assembly over.
3. Remove the six screws (M2x4) that secure the heat-sink assembly to the system board.
4. Lift the heat-sink assembly off the system board.
Installing the heat-sink assembly
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the heat-sink assembly and provides a visual representation of the installation
procedure.
CAUTION: Incorrect alignment of the heat sink can damage the system board and processor.
