1. Rear I/O cover
2. Base cover
3. Rubber grip
4. USB Type-C board
5. Memory modules
6. I/O board
7. Fan and heat-sink assembly
8. System board
9. Speakers
10.Palm-rest and keyboard assembly
11. Touchpad
12. Top heat-sink
13. Antenna holder
14. Display assembly
15.Audio board
16.Battery
17. M.2 2280 solid-state drive
18.M.2 2230 solid-state drive
19.Wireless card
20.Keyboard-controller board
21. Small fan
NOTE:
Computers that are shipped with NVIDIA GeForce RTX 4080 or RTX 4090 graphics card have two M.2 2230 and two M.2
2230/2280 solid-state drive slots.
Computers that are shipped with NVIDIA GeForce RTX 4060 or RTX 4070 graphics card have only two M.2 2230/2280
solid-state drive slots.
NOTE: Dell provides a list of components and their part numbers for the original computer configuration purchased. These parts
are available according to warranty coverage purchased by the customer. Contact your Dell sales representative for purchase
options.
