11. Remove the display cable and camera cable from the routing guides on the display assembly.
12. Remove the eight screws (M2.5x5) that secure the display assembly to the palm-rest and keyboard assembly.
13. Lift the display assembly off the palm-rest and keyboard assembly.
Installing the display assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the antennas and provide a visual representation of the installation procedure.
71
