Steps
After performing the pre-requisites, you are left with the palm-rest and keyboard assembly.
NOTE: Ensure that the solid-state drive mounts are removed from the old palm-rest and keyboard assembly before installing the
new palm-rest and keyboard assembly. Install these solid-state drive mounts into the new palm-rest and keyboard assembly.
Installing the palm-rest and keyboard assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image indicates the location of the palm-rest and keyboard assembly and provides a visual representation of the
installation procedure.
97
