Steps
Place the palm-rest and keyboard assembly on a flat and clean surface and perform the post-requisites to install the palm-rest and
keyboard assembly.
NOTE: Install the solid-state drive mounts from the old palm-rest and keyboard assembly into the new palm-rest and keyboard
assembly.
Next steps
1. Install the I/O board.
2. Install the power button.
3. Install the antennas.
4. Follow the procedure from step 5 to step 25 in Installing the system board.
5. Install the
display assembly.
6. Install the power-adapter port.
7. Install the speakers.
8. Install the USB Type-C board.
9. Install the keyboard-controller board.
10.Install the touchpad.
11. Install the
rear I/O cover.
12. Install the top heat-sink.
13. Install the small fan.
14. Install the M.2 2230 solid-state drive in slot three and four, if applicable.
15.Install the M.2 2280 solid-state drive or M.2 2230 solid-state drive in slot one and two, whichever is applicable.
16.Install the memory module.
17. Install the wireless card.
18.Install the battery.
19.Install the
base cover.
20.Follow the procedure in After working inside your computer.
