2. Install the rear I/O cover.
3. Install the top heat-sink.
4. Install the small fan.
5. Install the wireless card.
6. Install the
M.2 2230 solid-state drive in slot three and four, if applicable.
7. Install the M.2 2280 solid-state drive or M.2 2230 solid-state drive in slot one and two, whichever is applicable.
8. Install the memory module.
9. Install the
base cover.
10.Follow the procedure in After working inside your computer.
I/O board
Removing the I/O board
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the
base cover.
3. Remove the
battery.
4. Remove the wireless card.
5. Remove the M.2 2280 solid state drive or M.2 2230 solid-state drive in slot one and two, whichever is applicable.
6. Remove the M.2 2230 solid-state drive in slot three and four, if applicable.
7. Remove the small fan.
8. Remove the
top heat-sink.
9. Remove the rear I/O cover.
10.Follow the procedure from step 1 to step 20 in Removing the system board.
NOTE: The system board can be removed and installed along with the audio board and heat-sink assembly. This simplifies the
removal and installation procedure and avoids breaking the thermal bond between the system board and heat sink.
About this task
The following images indicate the location of the I/O board and provide a visual representation of the removal procedure.
