3. Install the base cover.
4. Follow the procedure in After working inside your computer.
Display assembly
Removing the display assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the rear I/O cover.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
69
