20 | Installing the Switch
www.dell.com | support.dell.com
Step Task
1 Align the three screw holes of the adjustable rear mounting bracket with the three holes in the unit, and secure the
mounting bracket with three screws.
2 Insert the unit into the rack, and secure the chassis to the front post with two screws. Then secure it to the rear
posts with two screws.
fn00146s50
V
fn00147s50V
