Installing Ports | 43
Installing Optics
This section contains two subsections:
• Installing SFPs on page 43
• Installing XFPs on page 44
The S50N and S50V each have four receptacles at the right end of their faceplates that accommodate
10/100/1000 SFP optical transceivers.
On the back of the switches, there are two bays that accept either stacking modules or 10GbE modules
(CX4 or XFP). A 10GbE module contains two ports. 10GbE modules should only be inserted or removed
when the switch is powered down, as detailed in
Inserting Optional Modules (10-Gigabit or Stacking) on
page 17
in
Chapter 4, Installing the Switch
.
SFP and XFP transceivers can be inserted or removed while the switch is running.
CAUTION: Before connecting a transceiver to a source, check the receive power of the transceiver with an
optical power meter. Generally, Dell Force10 specified optics are not to be subjected to receive power higher
than that stipulated by the optic specification. If the optic is exposed to optical power in excess of the
specification, there is a high likelihood that it will be damaged. Optical specifications for Dell Force10 branded
devices are at the following URL:
http://www.force10networks.com/products/mediaspecifications.asp
Dell Force10 offers various types of SFP and XFP transceivers. For details, see:
http://www.force10networks.com/products/specifications.asp
Installing SFPs
To install an SFP transceiver into an open optical port at the right front of the switch, use the steps below:
Table 6-2. PoE Commands
FTOS SFTOS
[no] power-budget stack-unit 0-7 321-790:
(CONFIGURATION mode) Enable PoE power from a 470W
Redundant Power Supply (catalog # S50-01-PSU-V), if
attached to the designated stack member.
inlinepower {disable | enable} unit-id: (Global Config
mode) Enable or disable PoE for a specified switch in an S-
Series stack.
inlinepower admin {off | auto}: (Interface Config mode)
Enable or disable PoE on a particular port.
[no] power inline {auto [max_milli-watts] | static [max_milli-
watts]}: (INTERFACE mode) Enable power to be supplied to
a device connected to a port
inlinepower limit
1-20:
(Interface Config mode) Set a power limit on the port.
[no] power inline priority {critical | high | low}:
(INTERFACE mode) Set the PoE priority of the port.
inlinepower priority {critical | high | low}: (Interface Config
mode) Set a PoE priority on the port.
show power inline: (EXEC, EXEC privilege modes) Display
the ports that are enabled with PoE and the amount of power
that each is consuming
inlinepower threshold
0-100 unit-id:
(Global Config mode) Override the 80% default limit of the
PoE power budget.
show power supply: (EXEC, EXEC privilege modes) Display
the power supply status.
show inlinepower [unit/slot/port
| all]:
(User Exec, Privileged Exec modes) Display the power status
for one or all ports.
