Dell Latitude 7310 Service Manual

How to run M-BIST
NOTE: M-BIST must be initiated on the system from a power-off state either connected to AC power or with battery
only.
1. Press and hold both the M key on the keyboard and the power button to initiate M-BIST.
2. With both the M key and the power button held down, the battery indicator LED may exhibit two states:
a. OFF: No fault detected with the system board
b. AMBER: Indicates a problem with the system board
RTC reset and Flea power release
About this task
Flea power is the residual static electricity that remains on the computer even after it has been powered off and the battery has been
disconnected from the system board. The following procedure provides the instructions on how to release the flea power:
Steps
1. Turn off your computer.
2. Remove the base cover.
NOTE: The battery must be disconnected from the system board, see Step 2 in Removing the SSD.
3. Press and hold the power button for 15 seconds to drain the flea power.
4. Install the base cover.
5. Turn on your computer.
NOTE: Performing a flea power also reset the RTC of the system. Update the system time and date at first startup.
Troubleshooting 61

Dell Latitude 7310 Specifications

General

Graphics	Intel UHD Graphics
Operating System	Windows 10 Pro
Wireless	Intel Wi-Fi 6 AX201, Bluetooth 5.1
Security	Fingerprint Reader, Smart Card Reader, TPM 2.0
Processor	10th Generation Intel Core i5/i7
Display	13.3-inch FHD (1920 x 1080)
Memory	Up to 32GB DDR4
Storage	Up to 1TB PCIe NVMe SSD
Weight	2.7 lbs (1.22 kg)
Ports	1 x microSD card reader, 1 x Universal Audio Jack
Battery	4-Cell 60 WHr ExpressCharge Capable Battery
