Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
10. System board
11. Optional palmrest
antenna
Hinges Palmrest assembly M2.5x4 4
F-beam FPC I/O daughterboard M2x3.5 2
USB Type-C bracket System board M2x5 3
Keyboard
1. Carbon Fiber
2. Aluminum
Palmrest assembly M1.6x2
_
1. 17
2. 21
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The following images indicate the location of the base cover and provide a visual representation of the removal procedure.
