Dell Latitude E6430 - Removing the Display-Hinge Caps; Installing the Display-Hinge Caps

Removing the Display-Hinge Caps
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) base cover
c) hard drive
d) bluetooth card
e) keyboard trim
f) keyboard
g) display assembly
3. Rotate the left and right hinges upwards to a vertical position.
4. Pry loose the edge of hinge cap from the hinge and remove the hinge caps from the display assembly.
Installing the Display-Hinge Caps
1. Slide the left hinge cap on the display panel.
2. Rotate the hinge downward to secure the hinge cap to the display panel.
3. Repeat steps 1 and 2 for the right hinge cap.
