Dell Latitude E6430 - Removing the Display Assembly

Installing the System Board
1. Place the system board on the chassis.
2. Tighten the screws to secure the system board to the computer.
3. Connect the media board cable.
4. Flip the computer and connect the following cables to the system board:
a) speaker
b) coin-cell battery
c) LVDS
5. Tighten the screw to secure the LVDS cable bracket.
6. Install the:
a) ExpressCard cage
b) media board
c) palmrest
d) display assembly
e) keyboard
f) keyboard trim
g) bluetooth card
h) optical drive
i) hard drive
j) base cover
k) battery
7. Follow the procedures in After Working Inside Your Computer .
Removing the Display Assembly
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) base cover
c) keyboard trim
d) keyboard
3. Remove the screw that secures the support bracket to the computer.
