3. Lift the base cover to remove it from the computer.
Installing the Base Cover
1. Place the base cover to align with the screw holes on the computer.
2. Tighten the screws to secure the base cover to the computer.
3. Install the battery.
4. Follow the procedures in
After Working Inside Your Computer
.
Removing the Keyboard Trim
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the battery.
3. Using a plastic scribe, pry under the keyboard trim to release it from the computer.
4. Pry the keyboard trim along the sides and bottom.
5. Lift up to remove the keyboard trim from the unit.
14
