Dell Latitude E6530 - Installing the Speakers; Removing the Coin-Cell Battery

Installing the Speakers
1. Align the speakers in the original position and connect the speaker cables.
2. Tighten the screws to secure the speakers.
3. Install:
a) system board
b) bluetooth card
c) ExpressCard cage
d) media board (available in E6430/E6430 ATG only)
e) palmrest
f) display assembly
g) keyboard
h) keyboard trim
i) hard drive
j) base cover
k) battery
4. Follow the procedures in
After Working Inside Your Computer .
Removing the Coin-Cell Battery
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) base cover
3. Disconnect the coin-cell battery cable.
4. Pry the coin-cell battery upward and remove it from the computer.
29
