i) battery
6. Follow the procedures in
After Working Inside Your Computer
.
Removing the Camera
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove:
a) battery
b) display assembly
c) display bezel
d) display panel
3. Disconnect the LVDS and camera cable from the camera.
4. Remove the screw that secures the camera to the display assembly.
5. Remove the camera from the display assembly.
56
