Dell Latitude E6530 - Installing the Keyboard; Removing the Hard Drive

Installing the Keyboard
1. Connect the keyboard cable and secure it to the keyboard using the tape.
2. Connect the keyboard cable to the system board.
3. Slide the keyboard into its compartment and ensure that it clicks into place.
4. Tighten the screws to secure the keyboard on the palmrest.
5. Flip the computer and tighten the screws to secure the keyboard.
6. Install:
a) keyboard trim
b) battery
7. Follow the procedures in
After Working Inside Your Computer .
Removing the Hard Drive
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery.
3. Remove the screws that secure the hard drive to the computer.
4. Slide the hard drive out of the computer.
17
