Dell Latitude E6530 - Installing the Camera; Removing the LVDS and Camera Cable

Installing the Camera
1. Install the camera in its slot on the display panel.
2. Tighten the screw to secure the camera to the display assembly.
3. Connect the LVDS and the camera cable to the camera.
4. Install:
a) display panel
b) display bezel
c) display assembly
d) battery
5. Follow the procedures in
After Working Inside Your Computer .
Removing the LVDS and Camera Cable
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a) battery
b) base cover
c) hard drive
d) bluetooth card
e) keyboard trim
f) keyboard
g) display assembly
h) display bezel
i) display panel
j) display hinges
3. Disconnect the LVDS and camera cable from the camera.
4. Peel back the adhesives securing the LVDS and camera cable to the display assembly.
57
