Dell Latitude E6530 - Page 44

e) keyboard trim
f) keyboard
g) display assembly
h) palmrest
i) media board (available in E6430/E6430 ATG only)
j) ExpressCard cage
k) system board
3. Disconnect the modem-card cable from the modem card.
4. Remove the modem cable from the routing channel.
5. Remove the screw that secures the modem-connector bracket to the computer.
6. Remove the modem-connector bracket from the computer.
44
