Installing an optional envelope feeder
The envelope feeder attaches to the front of your printer behind the lower front door. It can be removed
when you are not using it, making the printer more compact.
NOTE: It is normal for the envelope feeder to make a loud tapping sound while printing. See Envelope
Enhance for more information.
Press the release latch and open the printer lower front door.1.
Lift open the envelope feeder connector door.2.
Envelope feeder connector
door
Align the tabs on the envelope feeder with the slots on both sides of the printer, and then gently push
the envelope feeder into the opening until it snaps into place.
3.
The envelope feeder tilts downward at a slight angle when it is installed properly.
